SC-C925 Portable Freezer Cooler 25L

Widely used for from leisure to professional use

Discontinued Model

Key Features

SC-C925 is used in your life sceneries, such as camp, marine, and sport. It is also adaptive for professional use, such as business or researches.
SC-C925 prepares for simple 5 temperature button for set + 10℃、+ 6℃、+ 3℃、-7℃、-18℃. (Note that it is does not operate properly when the ambient temperature is lower than set temp.)


Typical performance

This cooling curve is the typical characteristic of internal temperature at empty cabinet, not guaranteed value. Note that cooling performance depends on heat mass and arrangement of contents strongly.

Your Industries

Portable Freezers

In case of no space for the refrigerator, such as small food stall, FPSC make possible to have refrigerated storage, once connected to DC power supply.
Tasty

FPSC are used for keeping food control at the optimum temperature for each frozen, chilled, refrigerated, and trying to keep taste and freshness.

FPSC

– State of the Art

FPSC, Free Piston Stirling Coolers, are the complete CFC free system, using natural He gas.
It is small, portable, and it is widely used for precise temperature control for under -50℃.
Twinbird succeeded in mass production through the collaborative network of craftsmanship in Tsubame-Sanjo.

suitable for cooling below -50℃. *1

*1 Optimum thermal insulation design for relatively small thermal mass is required.
Reach to -80 ℃ in a few minutes. *1

*1 Optimum thermal insulation design for relatively small thermal mass is required.
Precise temperature control system. *1

*1 Optimum thermal insulation design for relatively small thermal mass is required.
Total volume of FPSC is less than 3 liters. *2

*2：　In case of model SC-TG08S
Zero Global Warming Potential He gas is used for refrigerants to reduce environmental load.
FPSC based on the network of craftsmanship in Tsubame-Sanjo

Specifications

Dimensions (outside)	W D H: 695 x 350 x 460 (mm)
Dimensions (inside)	W D H: 335 x 225 x 340 (mm) , 25 liters
Weight	14.5 kg
Power Source Voltage	DC 12 Volts
Power Consumption	48 VA
Setting Temperature	+ 10℃、+ 6℃、+ 3℃、-7℃、-18℃. (ambient temp: 25℃) (Note that it is does not operate properly when the ambient temperature is lower than set temp.)
Noise	40 dB(A) (Horizontally 1 m from Cooler, after stable operation)
Include	SC-AD70 AC Adapter Cigarette Plug Cable (3m, DC12 Volts)
Sample Price	Please contact SC business division for detail.

Documents

Confirm if the product is suitable for your use before place order.
