SC-TG08S / Stirling Cooler TG08S

Standard cooler
For flexible install cooler and Drive PCB to your system

※SC-TD08 is discontinued.

SC-TG08S

Key Features

  • The SC-TG08S is a standard cooler, which is suitable for strict temperature control below – 80 ° C. Depending on the heat mass and temperature of object, cooling capacity and speed can be fine-tuned.

  • SC-TG08S can be installed on various applications, especially for portable type equipment because of its compactness and lightweight.

  • For customers who think more compact equipment design, cooler and Drive PCB are separated. The suitable fan is required to be installed for exhaust heat management, as the same with SC-TG08S.

  • “Vibration detector” on SC-TG08S automatically reduces the output instruction to suppress the abnormal vibration.


Typical performance

This cooling curve is the typical characteristic at no load, not guaranteed value. Note that cooling performance depends on each design of cooling system strongly. Referring user’s manual at our web-site, and confirm if our products are suitable for your use

New Function “Original Vibration suppression Technology”

1.Abnormal vibration Abnormal vibration with noise occurs in “(1) when cooling a large thermal load” or “(2) when a large thermal fluctuation occurs in the object to be cooled”.

2.”Vibration detector” protection DRIVE PCB suppresses and is idle FPSC operation forcibly when abnormal vibration is detected. After abnormal vibration with noise stops, DRIVE PCB starts to drive FPSC again.

Ask Question, Abnormal Vibration

※We also have products without a vibration detector. Please contact the SC Division for details.

Your Industries

  • Accurate ultra-low temperature

    FPSC accurate ultra-low temperature supports professional applications such as temperature calibration and inspection of electronic components.

  • Condense

    Condensing gases at ultra-low temperature enable to improve environmental measurement and semiconductor process.

FPSC

– State of the Art

FPSC, Free Piston Stirling Coolers, are the complete CFC free system, using natural He gas.
It is small, portable, and it is widely used for precise temperature control for under -50℃.
Twinbird succeeded in mass production through the collaborative network of craftsmanship in Tsubame-Sanjo.

  • suitable for cooling below -50℃. *1

    *1 Optimum thermal insulation design for relatively small thermal mass is required.

  • Reach to -80 ℃ in a few minutes. *1

    *1 Optimum thermal insulation design for relatively small thermal mass is required.

  • Precise temperature control system. *1

    *1 Optimum thermal insulation design for relatively small thermal mass is required.

  • Total volume of FPSC is less than 3 liters. *2

    *2: In case of model SC-TG08S

  • Zero Global Warming Potential He gas is used for refrigerants to reduce environmental load.

  • FPSC based on the network of craftsmanship in Tsubame-Sanjo

Specifications

Dimensions W D H: 130 x 130 x 280 (mm)
Weight 2.4 kg
Power Source Voltage DC 24 Volts
Maximum Current 10 Amp
Cooling Capacity 25 Watts at -80℃ at cooling head (ambient temp: 25℃)
Ambient Temp in Operation 0℃~35℃
Set Temp of Cooling head -20℃ or less
Noise 50 dB(A) (Horizontally 1 m from Cooler, after stable operation)
Include Drive PCB
Accessory SC-CA04 Cold Side Adapter
Sample Price 1,250 USD (ex. Work, Shipping fee is not included)
※This price is a reference price.
Formal quote will be provided at the time of purchase.
This price will

Documents

Confirm if the product is suitable for your use before place order.
