SC-UERF FPSC Module with Vacuum Flange

High power cooling for vacuum space

Key Features

suitable for strict temperature control at below than -100℃. Depending on the heat mass and temperature of object, cooling capacity and speed can be fine-tuned.
The flange of SC-UERF is designed to attach to your vacuum chamber easily. High insulation effect of vacuum structure make strict temperature control possible. Mount part for cooling head is also installed.
The fan is optimally integrated with cooler body, that becomes a heat source. You can flexibly design heat management of your system with separately prepared Driver PCB that becomes another heat source.

Typical performance

This cooling curve is the typical characteristic at no load, not guaranteed value. Note that cooling performance depends on each design of cooling system strongly.　Referring user’s manual at our web-site, and confirm if our products are suitable for your use.

Your Industries

Condense

Condensing gases at ultra-low temperature enable to improve environmental measurement and semiconductor process.
Accurate ultra-low temperature

FPSC accurate ultra-low temperature supports professional applications such as temperature calibration and inspection of electronic components .

FPSC

– State of the Art

FPSC, Free Piston Stirling Coolers, are the complete CFC free system, using natural He gas.
It is small, portable, and it is widely used for precise temperature control for under -50℃.
Twinbird succeeded in mass production through the collaborative network of craftsmanship in Tsubame-Sanjo.

suitable for cooling below -50℃. *1

*1 Optimum thermal insulation design for relatively small thermal mass is required.
Reach to -80 ℃ in a few minutes. *1

*1 Optimum thermal insulation design for relatively small thermal mass is required.
Precise temperature control system. *1

*1 Optimum thermal insulation design for relatively small thermal mass is required.
Total volume of FPSC is less than 3 liters. *2

*2：　In case of model SC-TG08S
Zero Global Warming Potential He gas is used for refrigerants to reduce environmental load.
FPSC based on the network of craftsmanship in Tsubame-Sanjo

Specifications

Dimensions	W H L: 180 x 170 x 435 (mm)
Weight	12 kg
Power Source Voltage	DC 48 Volts
Maximum Current	9 Amp
Cooling Capacity	15 Watts at -100℃ at cooling head (ambient temp: 25℃)
Ambient Temp in Operation	0℃～40℃
Set Temp of Cooling head	-20℃ or less
Noise	55 dB(A) (Horizontally 1 m from Cooler, after stable operation)
Include	Driver PCB
Sample Price	Please contact SC business division for detail.

Documents

Confirm if the product is suitable for your use before place order.
