SC-BV25 Vaccine Transport Box 25L
Key Features
-
The SC-BV25 is used for cold chain delivery where products should not be frozen, such as vaccine transport. It can be powered from wall plug or car cigar plug.
-
Even at ambient temperature below 0℃ it can keep 4 ℃ +/- 2℃ because SC-BV25 is hybrid configuration with FPSC and heater.
-
Internal temperature is indicated on the front panel. SC-BV25 has a memory for minimum/maximum temperature. It also alert when the temperature deviate.
Typical performance
This cooling curve is the typical characteristic of internal temperature at empty cabinet, not guaranteed value. Note that cooling performance depends on heat mass and arrangement of contents strongly.
Your Industries
-
Quality
Maintaining the safety and quality of products is the most important in the pharmaceutical industry. Precise temperature control during delivery is required to keep good quality, especially for vaccine and some biopharmaceuticals.
-
Delivery
No special freezer/ refrigerated trucks are required. FPSC make possible freezing/refrigerating transportation, once connected to DC power supply.
FPSC
– State of the Art
FPSC, Free Piston Stirling Coolers, are the complete CFC free system, using natural He gas.
It is small, portable, and it is widely used for precise temperature control for under -50℃.
Twinbird succeeded in mass production through the collaborative network of craftsmanship in Tsubame-Sanjo.
-
suitable for cooling below -50℃. *1
*1 Optimum thermal insulation design for relatively small thermal mass is required.
-
Reach to -80 ℃ in a few minutes. *1
*1 Optimum thermal insulation design for relatively small thermal mass is required.
-
Precise temperature control system. *1
*1 Optimum thermal insulation design for relatively small thermal mass is required.
-
Total volume of FPSC is less than 3 liters. *2
*2： In case of model SC-TG08S
-
Zero Global Warming Potential He gas is used for refrigerants to reduce environmental load.
-
FPSC based on the network of craftsmanship in Tsubame-Sanjo
Specifications
| Dimensions (outside) | W D H: 695 x 350 x 460 (mm) |
|---|---|
| Dimensions (inside) | W D H: 335 x 225 x 340 (mm) , 25 liters |
| Weight | 15 kg |
| Power Source Voltage | DC 12 Volts |
| Power Consumption | 48 VA |
| Setting Temperature | 4 ℃ +/- 2℃ (ambient temp -10℃ to 35℃) |
| Noise | 40 dB(A) (Horizontally 1 m from Cooler, after stable operation) |
| Include | 2 container box, Cigarette Plug Cable (3m, DC12 Volts) |
| Accessory | SC-AD70 AC Adapter |
| Sample Price | Please contact SC business division for detail. |
