SC-DF25 DEEP FREEZER 25L

Trump card for compact freezer in “Last one mile”

Key Features

  • Our high performance Stirling Cooler and vacuum insulation technology realized -40℃ at lowest with 1℃ increments of setting point.

  • SC-DF25 is used in the field of cold chain delivery where strict temperature control is required. It can be powered from wall plug or car cigar plug.

  • Our high performance Stirling Cooler and vacuum insulation technology realized -40℃ at lowest with 1℃ increments of setting point.


Typical performance

This cooling curve is the typical characteristic of internal temperature at empty cabinet, not guaranteed value. Note that cooling performance depends on heat mass and arrangement of contents strongly.

Your Industries

  • Quality

    Maintaining the safety and quality of products is the most important in the pharmaceutical industry. Precise temperature control during delivery is required to keep good quality, especially for vaccine and some biopharmaceuticals.

  • Delivery

    No special freezer/ refrigerated trucks are required. FPSC make possible freezing/refrigerating transportation, once connected to DC power supply.

FPSC

– State of the Art

FPSC, Free Piston Stirling Coolers, are the complete CFC free system, using natural He gas.
It is small, portable, and it is widely used for precise temperature control for under -50℃.
Twinbird succeeded in mass production through the collaborative network of craftsmanship in Tsubame-Sanjo.

  • suitable for cooling below -50℃. *1

    *1 Optimum thermal insulation design for relatively small thermal mass is required.

  • Reach to -80 ℃ in a few minutes. *1

    *1 Optimum thermal insulation design for relatively small thermal mass is required.

  • Precise temperature control system. *1

    *1 Optimum thermal insulation design for relatively small thermal mass is required.

  • Total volume of FPSC is less than 3 liters. *2

    *2: In case of model SC-TG08S

  • Zero Global Warming Potential He gas is used for refrigerants to reduce environmental load.

  • FPSC based on the network of craftsmanship in Tsubame-Sanjo

Specifications

Dimensions (outside) W D H: 695 x 350 x 460 (mm)
Dimensions (inside) W D H: 335 x 225 x 340 (mm) , 25 liters
Weight 15.5 kg
Power Source Voltage DC 12 Volts
Power Consumption 48 VA
Setting Temperature 1 ℃ increments, +10℃~ - 40℃ (ambient temp: 25℃) (Note that it is does not operate properly when the ambient temperature is lower than set temp.)
Noise 55 dB(A) (Horizontally 1 m from Cooler, after stable operation)
Include SC-AD70 AC Adapter
Cigarette Plug Cable (3m, DC12 Volts)
Sample Price Please contact SC business division for detail.

Documents

Confirm if the product is suitable for your use before place order.
